Quick Details
Standard:JIS,AISI,ASTM,GB,DIN,EN,GOST
Type:Seamless
Grade:AISI 304 /DIN 1.4301
Size:OD6mm-1024mm WT0.5mm-68mm LENGTH 50mM-12000mm
Application:Petroleum,Chemical Engineering,Fluid Machinery,Irrigation Works,Electric Power,Environmental,Etc
End:Plain End
Surface Finish:Brush polish,Hairline,160grit,Mirror,Bright,Etc
Technique:Cold rolling,Cold drawing
Test: Hardness Test,Hydrostatic Test,Ultrasonic Test,Eddy Current Test,Dimensional Checking,Chemical Analysis Etc
Inspection:100%
Price Term:FOB,CFR,CIF or as negotiation
| Stainless Steel Chemical Composition (%,max) |
| UNS | ASTM | DIN | JIS | C ≤ | Si ≤ | Mn ≤ | P ≤ | S ≤ | Ni ≤ | Cr ≤ | Mo | Others |
| S30400 | 304 | 1.4301 | SUS304 | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 8.00-11.00 | 18.00-20.00 | | |
| S30403 | 304L | 1.4306 | SUS304L | 0.035 | 0.75 | 2 | 0.04 | 0.03 | 8.00-13.00 | 18.00-20.00 | | |
| S30451 | 304N | 1.4315 | SUS304N1 | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 8.00-11.00 | 18.00-20.00 | | N:0.1-0.16 |
| S30900 | 309 | 1.4828 | SUS309 | 0.15 | 0.75 | 2 | 0.04 | 0.03 | 12.00-15.00 | 22.00-24.00 | | |
| S31000 | 310 | 1.4821 | | 0.15 | 0.75 | 2 | 0.04 | 0.03 | 19.00-22.00 | 24.00-26.00 | | |
| S31600 | 316 | 1.4401 | SUS316 | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 11.00-14.00 | 16.00-18.00 | 2.00-3.00 | |
| S31603 | 316L | 1.4404 | SUS316L | 0.035 | 0.75 | 2 | 0.04 | 0.03 | 10.00-15.00 | 16.00-18.00 | 2.00-3.00 | |
| S31700 | 317 | 1.4436 | SUS317 | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 11.00-14.00 | 18.00-20.00 | 3.00-4.00 | |
| S32100 | 321 | 1.4541 | SUS321 | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 9.00-13.00 | 17.00-20.00 | | Ti:5xC%-0.70B |
| S34700 | 347 | 1.455 | SUS347 | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 9.00-13.00 | 17.00-20.00 | | Nb+Ta:10xC%-1.00 |
| S31635 | 316Ti | 1.4571 | SUS316Ti | 0.08 | 0.75 | 2 | 0.04 | 0.03 | 11.00-14.00 | 16.00-18.00 | 2.00-3.00 | Ti:5xC%-0.75 |
| | | | | 0.03 | 1 | 2 | 0.02 | 0.02 | 4.5-6.5 | 21.00-23.00 | 2.50-3.50 | N:0.08-0.2 |
| | | | | 0.03 | 0.8 | 1.2 | 0.03 | 0.015 | 6.0-8.0 | 24.00-26.00 | 3.00-5.00 | N:0.24-0.32 |
| AMERICAN STANDARD CONTRAST FORM | |
| Nominal diameter in inches | External diameter in millimeters | ANSI B36.19 |
| 5s | 10s | Sched 40s | Sched 80s |
| mm | kg/m | mm | kg/m | mm | kg/m | mm | kg/m |
| 1/8" | 10.29 | | | 1.24 | 0.281 | 1.73 | 0.371 | 2.41 | 0.467 |
| 1/4" | 13.72 | | | 1.65 | 0.499 | 2.24 | 0.644 | 3.02 | 0.809 |
| 3/8" | 17.15 | | | 1.65 | 0.64 | 2.31 | 0.858 | 3.2 | 1.118 |
| 1/2" | 21.34 | 1.65 | 0.814 | 2.11 | 1.016 | 2.77 | 1.26 | 3.73 | 1.62 |
| 3/4" | 26.67 | 1.65 | 1.034 | 2.11 | 1.298 | 2.87 | 1.68 | 3.91 | 2.19 |
| 1" | 33.4 | 1.65 | 1.312 | 2.77 | 2.125 | 3.38 | 2.5 | 4.55 | 3.23 |
| 11/4" | 42.16 | 1.65 | 1.674 | 2.77 | 2.732 | 3.56 | 3.38 | 4.85 | 4.46 |
| 11/2" | 48.26 | 1.65 | 1.926 | 2.77 | 3.155 | 3.68 | 4.05 | 5.08 | 5.4 |
| 2" | 60.33 | 1.65 | 2.424 | 2.77 | 3.992 | 3.91 | 5.43 | 5.54 | 7.47 |
| 21/2" | 73.03 | 2.11 | 3.747 | 3.05 | 5.345 | 5.16 | 8.62 | 7.01 | 11.4 |
| 3" | 88.9 | 2.11 | 4.585 | 3.05 | 6.557 | 5.49 | 11.28 | 7.62 | 15.25 |
| 31/2" | 101.6 | 2.11 | 5.272 | 3.05 | 7.526 | 5.74 | 13.56 | 8.18 | 18.62 |
| 4" | 114.3 | 2.11 | 5.945 | 3.05 | 8.496 | 6.02 | 16.06 | 8.56 | 22.29 |
| 5" | 141.3 | 2.77 | 9.639 | 3.4 | 11.74 | 6.55 | 21.76 | 9.52 | 30.92 |
| 6" | 168.3 | 2.77 | 11.514 | 3.4 | 14.037 | 7.11 | 28.23 | 10.97 | 42.52 |
| 8" | 219.08 | 2.77 | 15.049 | 3.76 | 20.334 | 8.18 | 42.49 | 12.7 | 64.57 |
| 10" | 273.05 | 3.4 | 23.028 | 4.19 | 28.29 | 9.27 | 60.24 | 12.7 | 81.46 |
| 12" | 323.85 | 3.96 | 31.806 | 4.57 | 36.633 | 9.52 | 73.76 | 12.7 | 97.36
|
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)
20 feet container load 25tons pipes whose length is under 5.8m
40 feet container load 28tons pipes whose length is under 11.8m
Q1: Wonder if you accept small orders?
A1: Do not worry. Feel free to contact us. In order to get more orders and give our clients more convener ,we accept small order.
Q2: Can you send products to my country?
A2: Sure, we can. If you do not have your own ship forwarder, we can help you.
Q3: Can you do OEM for me?
A3: We accept all OEM orders,just contact us and give me your design.we will offer you a reasonable price and make samples for you ASAP.
Q4: What's your payment terms ?
A4: By T/T,LC AT SIGHT,30% deposit in advance, balance 70% before shipment.
Q5: How long is your production lead time?
A5:It depends on product and order qty. Normally, it takes us 15 days for an order with MOQ qty.
Q6: When can I get the quotation ?
A6: We usually quote you within 24 hours after we get your inquiry. If you are very urgent to get the quotation.Please call us or tell us in your mail, so that we could regard your inquiry priority.
